Features and configurations
|
|
|
Form factor
|
Micro-ATX
|
|
AA# (Altered Assembly)
|
G81311-100
|
|
BIOS ID string
|
BFH6110H.86A
|
|
Processor
|
At product launch, this desktop board supports all 2nd and 3rd generation Celeron® and Intel® Core™ i7/i5/i3 processors in an LGA1155 socket with a 95W TDP.
View all compatible Intel® processor numbers
|
|
Memory
|
Two 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
Support for DDR3 1333 /1066 MHz DIMMs
Support for up to 16 GB1 of system memory
|
|
Chipset
|
Intel® H61 Express Chipset
|
|
Audio
|
Intel® High Definition Audio (Intel® HD Audio)2 subsystem in the following configuration:
6-channel audio subsystem with three analog audio outputs.
|
|
Graphics
|
VGA and DVI-D connector for processors with Intel® HD Graphics
|
|
LAN support
|
Gigabit Ethernet controller
|
|
Peripheral interfaces
|
Eight USB 2.0 ports (4 external ports, 4 via internal headers)
Four Serial ATA ports
Two PS/2 ports
One Serial Header
|
|
Expansion capabilities
|
One PCI Express* 3.0 x16 bus add-in card connectors
Two PCI Express* x1 connectors
|
